PL800 Palletising Robot; 800 kg Heavy-Duty Automation
PL800 Palletising Robot; 800 kg Heavy-Duty Automation
Meet the Yaskawa PL800: a 4-axis palletising robot with 800 kg payload, 3,159 mm reach & 1,700+ cycles/hr, ideal for heavy industrial automation.
Overview
Introducing the MOTOMAN PL800, Yaskawa’s most powerful 4-axis robot in the PL series, built for high throughput, large payloads, and versatile palletising in logistics and packaging environments.
The Yaskawa MOTOMAN PL800 is engineered for demanding palletising and depalletizing operations, delivering robust automation performance. With a payload capacity of 800 kg and a reach of 3,159 mm, it can manage full pallet layers or heavy product stacks with ease. Its repeatability of 0.05 mm and cycle capability of over 1,700 cycles per hour enable precise and efficient handling. The PL800 supports stacking heights above 2,600 mm and offers flexible floor mounting options. Integrated into Yaskawa’s ecosystem, it combines data support through CAD, datasheets, and control compatibility to streamline system design and deployment.
- High-Speed Palletizing: Achieve exceptional throughput with over 1,700 cycles per hour.
- Heavy-Duty Payload: Handle a wide range of products with a robust 190 kg payload capacity.
- Extended Reach & Stacking: Maximize workspace utilization with a 3,159 mm reach and over 2,600 mm stacking height.
- Optimized Efficiency: Streamline end-of-line packaging and logistics with reliable 4-axis robotic automation.
Technical Details
- Number of Axis
- 5
- Payload
- 80 kg
- Max Working Range
- 2061 mm
- Repeatability
- 0.03 mm
- Weight
- 565 kg
- Power Supply
- 4.5 kVA
- Maximum Speed S Axis
- 180 °/s
- Maximum Speed L Axis
- 180 °/s
- Maximum Speed U Axis
- 180 °/s
- Maximum Speed B Axis
- 180 °/s
- Maximum Speed T Axis
- 500 °/s
- Mounting Options
- Floor
- Further Specifications
- x No
Downloads
| Name | |||
|
Flyer Robot PL80
Palettieren mit der PL-Serie Data sheet | German |
Data sheet | German | |
|
Flyer Robot PL80
Palletizing with the PL-Series Data sheet | English |
Data sheet | English | |
| PL80_2D CAD/CAE | | CAD/CAE | ||
| PL80_3D CAD/CAE | | CAD/CAE | ||
| Flyer Robot PL80 Data sheet | French | Data sheet | French |
